230V Industrial Power Conditioning for Electron Microscopy
The ONEAC CSS2248 is an industrial-grade power conditioner designed to provide clean, stable, and isolated power to sensitive laboratory equipment. It is well suited for SEM, FIB, detector systems, and EMO circuit integration where electrical stability is essential.
Electrical Specifications
Input: 230 V AC (configured on 240 V primary tap)
Frequency: 50 / 60 Hz
Phase: Single phase
Output: 230 V AC
Max Output Current: 20 A
Operating Range: 207 – 253 V
Performance
97% efficiency
±2% load regulation
<2 ms response time
High RF noise attenuation (up to 50 dB typical)
ANSI/IEEE surge protection
<1% added THD
Application
Designed to protect sensitive electronics from:
Voltage fluctuations
Electrical noise
Transient surges
Ground loop disturbances
Suitable for integration into electron microscope power systems and other precision laboratory installations.
Used unit. Industrial construction. Hardwired configuration.
