⚙️ Edwards iQDP40 — Key Technical Specifications
Inlet connection : ISO-63 bolted
Exhaust / outlet : NW40
Weight : ~ 186 kg (≈ 410 lbs)
Motor / Power input: 3-phase, 208-230 / 380-415 V, 50 / 60 Hz. Motor power ~2.2 kW (for typical build)
Pumping Speed : Depending on version: ~ 44 m³/h (≈ 26-28 m³/h in some configs), in others higher (~ 55-60 m³/h) for 60 Hz.
Ultimate Pressure : (vacuum) On the order of 2-5 × 10⁻² Torr (≈ 2-5 × 10⁻² Torr ≈ 0.025-0.05 Torr) = approx 3 × 10⁻² mbar to 5 × 10⁻² mbar in many specs.
Cooling : Water-cooled motor and cooling system.
Purge Capability : Can be configured with gas purge (nitrogen) up to something like 50 SLM for harsh duty in certain versions.
Additional / System / Controller Info
The iQDP40 includes integrated electronics and monitoring (“pump health outputs”) when used with its controller/interface modules.
It can be integrated via Interface Modules or via Tool/Network Interface Modules for remote control and diagnostics.
